LT Control Cables

High-speed centrifugal sieve for continuous, dust-free screening and separation of powders with precise particle size control.

Attribute	Specification
Screen Diameter	300 mm – 1500 mm (customizable)
Mesh Size	75 µm – 5 mm
Capacity	100 kg/hr – 10 tons/hr
Construction Material	Mild Steel, SS304/SS316 for food & pharma
Drive System	High-speed motor with balanced paddles
Applications	Food, chemical, pharma, agro-processing & minerals

Description

Application : Cables for Power Supply to equipments, panel boards & distribution boards
Type : 1.1 kV as per IS:1554-I & IS 7098-1
Size : 1.5 sq. mm & 2.5 sq. mm – from 2 Core to 61 Core
Additional Features : FR/FR-LSH/LSZH
Insulated Material : XLPE; PVC
Armoured/Unarmoured : Higher current rating and emergency overload rating; Superoir short circuit rating; Low dielectric loss; Much better insulation resistance; Resistant to chemical & corrossive gases etc.; Better resistance to surge currents; Much longer life of the cables N/A”
PVC Insulated Cable : High dielectric strength & resistance to D.C. voltage effects; High mechanical strength & resistance to abrasion, vibration & ageing; Resistant to most acids, alkalies, to temporary contact with solvents, oils and liquid fluids; Flame retardant, does not support combustion and self-extinguishing”
Suitable for short/long Runs & auxiliary loads
Reliable Performance, Mechanical Durability, Weather Resistant & Shock Resistant
Class-1/class-2 Conductor
